规格 主要尺寸和重量 Size Main Dimensions and Weight
| 规格DN Size |
主要尺寸 Main Dimensions（mm) |
电装型号Electric Actuator Code |
重量Weight |
| mm |
in |
d |
L |
H |
D0 |
L1 |
L2 |
| 1500Lb |
| 80 |
3 |
64 |
390 |
1030 |
305 |
400 |
555 |
SMC-00 |
265 |
| 1077 |
305 |
410 |
565 |
SMC-0 |
270 |
| 100 |
4 |
84 |
480 |
1033 |
305 |
410 |
565 |
SMC-0 |
384 |
| 1070 |
305 |
420 |
654 |
SMC-1 |
490 |
| 125 |
5 |
100 |
580 |
1125 |
305 |
420 |
654 |
SMC-1 |
520 |
| 1135 |
457 |
440 |
688 |
SMC-2 |
642 |
| 150 |
6 |
125 |
630 |
1681 |
305 |
420 |
654 |
SMC-1 |
804 |
| 200 |
8 |
158 |
770 |
1960 |
305 |
420 |
654 |
SMC-1 |
948 |
| 2500Lb |
| 65 |
21/2 |
46 |
420 |
975 |
305 |
410 |
565 |
SMC-0 |
390 |
| 1015 |
305 |
420 |
654 |
SMC-1 |
600 |
| 80 |
3 |
54 |
470 |
1065 |
305 |
410 |
565 |
SMC-0 |
430 |
| 1095 |
305 |
420 |
654 |
SMC-1 |
430 |
| 100 |
4 |
70 |
570 |
1220 |
305 |
420 |
654 |
SMC-1 |
640 |
| 1235 |
457 |
440 |
688 |
SMC-2 |
772 |
| 125 |
5 |
88 |
660 |
1425 |
457 |
440 |
688 |
SMC-2 |
772 |
| 1500 |
610 |
690 |
840 |
SMC-3 |
810 |
| 150 |
6 |
104 |
760 |
1480 |
457 |
440 |
688 |
SMC-2 |
872 |
| 1685 |
610 |
690 |
840 |
SMC-3 |
917 |
|
